Power System Analysis and design

Introducing

Hello

I'm Arsi Khan

Welcome to the forefront of power excellence! I am  Engr. Arsalan , a seasoned Power System Analysis and Design Engineer with over a decade of industry expertise. As a driving force behind some of the most innovative projects, I bring a wealth of experience to the table, ensuring robust, efficient, and cutting-edge solutions for your power system needs.

Power System Modeling & analysis

The Concept becomes Reality here .

Switch Gear / Panels

Let us analyse the BUSBAR what we got at hand.

Sinlge Line Diagram

The magic of CAD comes to play.

Technical Services

Shop drawings, Techincal solutions, other related projects are dealt here

My Skills

Why Hire Me For Next Project?

Being an experienced professional Electrical Engineer, the field of Electrical power system analysis and Design, is my passion, and I love to solve the new queries.

I am a problem solver and will go to extreme lengths to help my Clients /associates to get the perfect results.

I am very proficient in electrical CAD design, Switch gear, and  technical aspects also. I can get you the results with amazing response and delivery time.

Please do review my detailed experience info in the below CV.

Project 1

The Solar Farm is Design concept at 2023 W. GENESSEE ST, TOWN OF AUBURN,CAYUGA COUNTY, NY 13201.

The design model is made in Etap Software to illustrate the complete Power system studies, that include ( modelling, Load Flow analysis, Short Circuit fault Analysis , protection and coordination analysis.

The project is further sub divided in 4 x5MW solar  farms , that combine with the main grid to give an overall generation of 20 Megawatt of  Green Power.

Project 2

The Data center For VERIZON USA is under study for this Project. The main aim to reach here is complete model Load flow , Short circuit fault analysis, Arc Flash Hazard and the PRD for the complete Model.

The whole system from HV to the LV was modeled, and all the studies are performed with complete reports, Load Flow reports (with normal and Emergency Scenario),Short circuit Fault Reports , Etap Files, TCC Curves, Device setting reports in excel and arc flash report , plus Warning stickers were also printed for the project.

Project 3

The Concept was hand drawn and the image with details for Pumps & fans was provided by Engr. Ricardio  for TR-1 , TR-2.

Depending upon the Load the equipment was sized , and the cables were modelded as well. GCP (Generator Control Panel) and Transformers were sized as well.

The complete Riser SLD was made in AutoCAD 2024 from the Utility source to the final DB loads. as evident in the Image.

VFD for the Pumps and the Fans was a major goal for this project , for that we used ABB VFDs and other controls as per requirements.
